027N3038
Danfoss 027N3038 - Flange set, Flange, 50 mm, Butt weld
- Connection standard: ASME B 36.10M SCHEDULE 40
- Material Spec.: Steel
- Used for product: PMFH 300; PMLX 50; PMFL 300; PML 50; PM 50
Product details
| Connection size [in] | 2 in | |
| Connection size [mm] | 50 mm | |
| Connection standard | ASME B 36.10M SCHEDULE 40 | |
| Connection type | Butt weld | |
| Contain batteries | No | |
| Flange design | Tongue | |
| Flange form | Square | |
| Flange version | 12.0 | |
| Material Spec. | Steel | |
| Packing format | Multi pack | |
| Parts included | 2 flanges | |
| Product group | Flanges | |
| Product Name Description | Flange set | |
| Quantity per packing format | 4 pc | |
| REACH Candidate List substances | No | |
| Type | Flange | |
| Used for product | PMFH 300; PMLX 50; PMFL 300; PML 50; PM 50 |
Technical data
| Product type | Flanges | |
| Net weight | 3.05 kg | |
| Gross weight | 3.161 kg | |
| Packed volume | 1.6 L | |
| EAN | 5702428196789 | |
Documents
Operating guides, design guides, certificates and CAD drawings for 027N3038 are available on request. Ask for documents →
