084B4664
Danfoss 084B4664 - Refrig appliance control (TXV), EKC 302D
- Function: Comp.,Defrost,Fan,Alarm,More f
- Controller type: Refrig. Controller (Temp)
- Communication type: RS485; MODBUS
- Packing format: Industrial pack
- Quantity per packing format: 9
Product details
| Analog inputs (AI) [pc] | 3 pc | |
| Application area | Temperature control | |
| Approval | C-TICK; CE; EAC; CMIM | |
| CE evaluated | Yes | |
| China RoHS compliance | Out of scope | |
| Communication type | MODBUS; RS485 | |
| Controller type | Refrig. Controller (Temp) | |
| Digital inputs (DI) [pc] | 2 pc | |
| Digital outputs (DO) [pc] | 4 pc | |
| Display - option | EKA 163A; EKA 164A | |
| Display on front | Yes | |
| EU RoHS compliance | Out of scope | |
| Frequency [Hz] | 50/60 Hz | |
| Function | Comp.,Defrost,Fan,Alarm,More f | |
| Further information | Alarm= Light or Railheat | |
| Identical product | 084B4164 | |
| Number of Compressors max. | 1 pc | |
| Number of Evaporators max. | 1 pc | |
| Number of Sensor inputs | 3 pc | |
| Other RoHS documentation | EAEU RoHS | |
| Packing format | Industrial pack | |
| Power consumption [VA] | 2.3 VA | |
| Product accessories | Electron. control accessories | |
| Product group | Evaporator and room control | |
| Product Language | English | |
| Product Name Description | Refrig appliance control (TXV) | |
| Quantity per packing format | 9 pc | |
| REACH Candidate List substances | No | |
| Sensor type | Temp.Sensors | |
| Serviceable | No | |
| Supply voltage [V] AC | 230 V | |
| Temp. sensor support | NTC-M2020; PTC 1000; Pt 1000 | |
| Type | EKC 302D | |
| UK RoHS compliance | Out of scope | |
| Valve output type | EVR (TXV) |
Technical data
| Product type | Evaporator and room control | |
| Net weight | 0.317 kg | |
| Gross weight | 0.383 kg | |
| Packed volume | 1.3 L | |
| EAN | 5702428890335 | |
Documents
Operating guides, design guides, certificates and CAD drawings for 084B4664 are available on request. Ask for documents →
