003N3205
Pressure operated water valve, WVFX 20, 4 bar - 23 bar, 3.4 m³/h
Connection type: G · Connection size [in]: 3/4 · Kv value [m³/h]: 3.4
003N4410
Pressure operated water valve, WVFX 25, 15 bar - 29 bar, 5.5 m³/h
Connection type: G · Connection size [in]: 1 · Kv value [m³/h]: 5.5
003N2117
Pressure operated water valve, WVFX 25, 3.5 bar - 16 bar, 5.5 m³/h
Connection type: G · Connection size [in]: 1 · Kv value [m³/h]: 5.5
003N4100
Pressure operated water valve, WVFX 25, 3.5 bar - 16 bar, 5.5 m³/h
Connection type: G · Connection size [in]: 1 · Kv value [m³/h]: 5.5
003N4101
Pressure operated water valve, WVFX 25, 3.5 bar - 16 bar, 5.5 m³/h
Connection type: G · Connection size [in]: 1 · Kv value [m³/h]: 5.5
003N4104
Pressure operated water valve, WVFX 25, 4 bar - 23 bar, 5.5 m³/h
Connection type: G · Connection size [in]: 1 · Kv value [m³/h]: 5.5
003N4105
Pressure operated water valve, WVFX 25, 4 bar - 23 bar, 5.5 m³/h
Connection type: G · Connection size [in]: 1 · Kv value [m³/h]: 5.5
003N4411
Pressure operated water valve, WVFX 25, 4 bar - 26 bar, 5.5 m³/h
Connection type: NPT · Connection size [in]: 1 · Kv value [m³/h]: 5.5
003F1232
Pressure operated water valve, WVFX 32, 4 bar - 17 bar, 11 m³/h
Connection type: G · Connection size [in]: 1 1/4 · Kv value [m³/h]: 11
003N5207
Pressure operated water valve, WVO 10, 16 bar - 20 bar, 1.4 m³/h
Connection type: G · Connection size [in]: 3/8 · Kv value [m³/h]: 1.4
003N6212
Pressure operated water valve, WVO 10, 16 bar - 20 bar, 1.4 m³/h
Connection type: G · Connection size [in]: 3/8 · Kv value [m³/h]: 1.4
003N6232
Pressure operated water valve, WVO 20, 16 bar - 20 bar, 3.4 m³/h
Connection type: G · Connection size [in]: 3/4 · Kv value [m³/h]: 3.4
003N6215
Pressure operated water valve, WVO 20, 6 bar - 10 bar, 3.4 m³/h
Connection type: G · Connection size [in]: 3/4 · Kv value [m³/h]: 3.4
016D5040
Valve body for water reg.valve, WVH, 1 1/2
Connection size [in]: 1 1/2 · Connection type: G · Differential pressure [bar] [min]: 0.5
016D5032
Valve body for water reg.valve, WVH, 1 1/4
Connection size [in]: 1 1/4 · Connection type: G · Differential pressure [bar] [min]: 0.5
016D5065
Valve body for water reg.valve, WVH, 2 1/2 in
Connection size [in]: 2 1/2 in · Connection type: Weld flange · Differential pressure [bar] [min]: 0.3
016D5050
Valve body for water reg.valve, WVH, 2 in
Connection size [in]: 2 in · Connection type: Weld flange · Differential pressure [bar] [min]: 0.3
016D5080
Valve body for water reg.valve, WVH, 3 in
Connection size [in]: 3 in · Connection type: Weld flange · Differential pressure [bar] [min]: 0.3
016D5100
Valve body for water reg.valve, WVH, 4 in
Connection size [in]: 4 in · Connection type: Weld flange · Differential pressure [bar] [min]: 0.3
061L5003
Pressure operated water valve, AWR, 17.7 bar
Type designation: AWR-1203GLW · Control pressure range [bar]: 17.7 · Packing format: Multi pack
061L5000
Pressure operated water valve, AWR, 17.7 bar
Type designation: AWR-1504GLW · Control pressure range [bar]: 17.7 · Packing format: Multi pack
061L5004
Pressure operated water valve, AWR, 17.7 bar
Type designation: AWR-2006GLW · Control pressure range [bar]: 17.7 · Packing format: Multi pack
061L5009
Pressure operated water valve, AWR, 17.7 bar
Type designation: AWR-3212GLW · Control pressure range [bar]: 17.7 · Packing format: Multi pack
003F1240
Pressure operated water valve, WVFX 40, 4 bar - 17 bar, 11 m³/h
Connection type: G · Connection size [in]: 1 1/2 · Kv value [m³/h]: 11
