003Z1068
Danfoss 003Z1068 - MSV-F2, DN 250, PN 16, Flange
Similar products
- Genuine Danfoss products
- Danfoss manufacturer warranty
- Reply within one business day
- Worldwide delivery
Product details
| Type | MSV-F2 | |
| Product group | Manual balancing | |
| China RoHS compliance | Out of scope | |
| Connection types | Flange | |
| Contains batteries | No | |
| Description | MSV-F2 DN 250 with test plugs PN16, manual balancing valve | |
| Differential pressure over the valve [kPa] [Max] | 150 KPa | |
| Drain function | No | |
| EU RoHS compliance | Yes with exemptions | |
| EU RoHS exemption clause | 6(c) | |
| Kvs values [m³/h] | 952.3 m³/h | |
| Media temperature [°C] [Max] | 130 °C | |
| Media temperature [°C] [Min] | -10 °C | |
| Pressure class | PN 16 | |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) | |
| SCIP dossier product name | MSV-F2 MNF DN15-300 | |
| Setting scale | Yes | |
| Shut-off function | Yes | |
| Test plugs | With test plugs | |
| Valve body material | Cast iron (EN-GJL-250) | |
| Valve size | DN 250 |
Technical data
| Product type | Manual balancing | |
| Net weight | 323 kg | |
| Gross weight | 354 kg | |
| Packed volume | 691.2 L | |
| EAN | 5702420079974 | |
Documents
Operating guides, design guides, certificates and CAD drawings for 003Z1068 are available on request. Ask for documents →
