097C4697
Danfoss 097C4697 - BOCK, HGX12/30-4 ML CO2 T, Semi-hermetic CO2 transcritical
- Refrigerants: R744
- Compressor power supply [V]: 220-240V D / 380-420V Y -3- 50Hz
- Oil type: BOCKlub E85
- Anti-vibration pads: No
- Legacy BOCK ID: 16431
Type:
HGX12/30-4 ML CO2 T
HGX12/30-4 ML CO2 T
Similar products
- Genuine Danfoss products
- Danfoss manufacturer warranty
- Reply within one business day
Product details
| Type | HGX12 | |
| Product group | Semi-hermetic compressors | |
| Product Name Description | Reciprocating compressor HG | |
| Anti-vibration pads | No | |
| Approval standard | No | |
| Brand | BOCK | |
| Colour | Blue (standard) | |
| Compressor power supply [V] | 220-240V D / 380-420V Y -3- 50Hz | |
| Contains batteries | No | |
| Cylinder | 2 | |
| Description | Compressor HGX12/30-4 ML CO2 T | |
| Discharge connection size [in] | 3/4 in | |
| Discharge connection size [mm] | 19 mm | |
| Discharge connection size type | Non-Standard | |
| Discharge connection type | Soldering/welding | |
| Family | HG CO2 T Compressors | |
| Frequency Hz | 50 | |
| Hot gas temperature sensor | No | |
| In scope of WEEE | No | |
| IP class | IP66 | |
| Legacy BOCK ID | 16431 | |
| Max pressure (PS) - high side | 150 bar | |
| Max pressure (PS) - low side | 100 bar | |
| Model number | HGX12/30-4 ML CO2 T | |
| Motor protection | INT69 G 115-230V AC, 50/60 Hz, IP00 | |
| Oil level regulator | No | |
| Oil sump heater | 220-240V AC (V2A) | |
| Oil temperature sensor | No | |
| Oil type | BOCKlub E85 | |
| Phase | 3 | |
| Pressure relief valves | Only HP side | |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) | |
| Refrigerants | R744 | |
| SCIP dossier product name | HG(X)12/…. CO2 T/LT | |
| Screw-in valve | No | |
| Suction connection size [in] | 7/8 in | |
| Suction connection size [mm] | 22 mm | |
| Suction connection size type | Non-Standard | |
| Suction connection type | Soldering/welding | |
| Technology | Semi-hermetic CO2 transcritical | |
| Terminal box reduced/steel TB | No | |
| Thermal protection thermostat | No | |
| Type designation | HGX12/30-4 ML CO2 T |
Technical data
| Product type | Semi-hermetic compressors | |
| Net weight | 96.412 kg | |
| Gross weight | 105.812 kg | |
| Packed volume | 152.5 L | |
| EAN | 5715162646113 | |
Documents
Operating guides, design guides, certificates and CAD drawings for 097C4697 are available on request. Ask for documents →
